Read these original operating instructions and the enclosed safety instructions before using the device for the first time. Proceed accordingly.

Keep both books for future reference or for future owners.

Use the device as a wet/dry vacuum cleaner:

• For vacuuming floors and wall surfaces

• For vacuuming moist and liquid substances

• For vacuuming dry, non-flammable dust particles from machines

• For industrial use,e.g. in storage and production areas

• For commercial use, e.g. in hotels, schools, hospitals, factories, shops, offices, and rental companies.

The following are not in accordance with the intended use:

• Vacuuming of substances harmful to health and inflammable substances.

The packing materials can be recycled. Please dispose of packaging in accordance with the environmental regulations.

Electrical and electronic devices contain valuable, recyclable materials and often components such as batteries, rechargeable batteries or oil, which - if handled or disposed of incorrectly - can pose a potential danger to human health and the environment. However, these components are required for the correct operation of the device. Devices marked by this symbol are not allowed to be disposed of together with the household rubbish.

Current information on content materials can be found at: www.kaercher.de/REACH

Only use original accessories and original spare parts. They ensure that the appliance will run fault-free and safely.

Information on accessories and spare parts can be found at www.kaercher.com.

The warranty conditions issued by our relevant sales company apply in all countries. We shall remedy possible malfunctions on your appliance within the warranty period free of cost, provided that a material or manufacturing flaw is the cause. In a warranty case, please contact your dealer (with the purchase receipt) or the next authorised customer service site.

Further information can be found at: www.kaercher.com/dealersearch

Further warranty information (if available) can be found in the service area of your local Kärcher website under "Downloads".

The appliances:

• IVS 100/55

• IVS 100/75

are equipped with a radio receiver for the optionally available wireless remote control.

1. Bring the device into the working position and secure with the parking brake if necessary.

2. Insert the suction hose into the suction hose connection.

3. Plug the desired accessory onto the suction hose.

4. Ensure that vacuum cleaner waste container is inserted correctly.

1. Connect the mains plug.

2. Switch on the device at the main switch.

1. Connect the mains plug.

2. Switch on the device at the main switch.

3. Press the "Switch-on device" button.

1. Perform vacuuming.

2. Regularly check the filling level in the dirt receptacle, since the device does not switch off automatically.

3. Empty the vacuum cleaner waste container as necessary.

4. Clean or replace the filter as necessary.

A pressure gauge showing the vacuum inside the device is mounted on the front of the device.

1. Switch off the device at the"ON/IFF switch".

2. Move the filter cleaning lever back and forth several times.

1. Press "Switch off device" button.

2. Move the filter cleaning lever back and forth several times.

If this cleaning does not result in an improvement, the filter can be removed and washed or replaced (see section"Changing the filter").

A dust collection bag can be inserted in the vacuum cleaner waste container to allow dust-free emptying of the device.

1. Insert the dust collection bag in the vacuum cleaner waste container and carefully press it against the wall of the container.

2. Pull the edge of the dust collection bag over the edge of the vacuum cleaner waste container.

3. Insert the vacuum cleaner waste container into the device.

4. On completion of vacuuming, close the dust collection bag and remove it from the vacuum cleaner waste container.

5. Dispose of the dust collection bag according to the applicable waste disposal regulations.

1. Allow the wet filter to dry completely or replace it with a dry filter before using the device for dry vacuuming.

2. Replace the filter if necessary.

On completion of wet vacuuming:

1. Dry the filter

2. Clean the container with a moist cloth and dry it off.

The vacuum cleaner waste container must be emptied when it is has filled up to approx. 3 cm below the upper edge.

1. Switch off the device.

2. Secure the device using the parking brakes on the steering rollers.

3. Open the lock on the vacuum cleaner waste container upwards.

4. Pull the vacuum cleaner waste container out of the device.

   ---



5. Empty the vacuum cleaner waste container and insert it back into the device in the reverse order.

1. Switch off the device at the main switch.

2. Pull out the mains plug.

1. Switch off the device.

2. Remove the accessory and, if necessary, flush it out with water and allow to dry.

3. Empty the vacuum cleaner waste container (see section "Emptying the vacuum cleaner waste container").

4. Vacuum off the inside and outside of the device and clean with a moist cloth.

No periodic maintenance intervals are specified for this device. The following maintenance is to be performed as necessary:

• Wash the filter.

• Change the filter.

• Replace the filter.

Have the vacuum cleaner regularly inspected according to the respective national accident prevention regulations. Maintenance work as specified by the manufacturer must be performed by a technically qualified person at the specified regular intervals and in accordance with the applicable regulations and safety requirements. Work on electrical components may only be performed by a qualified electrician. Please contact a KÄRCHER branch office if you have any questions.

The filter can be washed out under running water.

---

1. Filter chamber lid

2. Filter spreader

3. Main filter

4. Sealing ring

1. Release the lower end of the suction turbine hose and pull it off.

2. Open the locks.

3. Remove the filter chamber lid.

4. Remove the filter.

5. Check the sealing ring for damage.

6. Insert the new filter in reverse sequence and take care to ensure that the filter spreader is aligned correctly in the filter bag.

• The motor (suction turbine) does not start running

• No vacuuming operations, airflow escapes from the suction hose.

• Suction power slowly reduces

• Escaping dust when vacuuming

Cause:

No electrical voltage present

Remedy:

• Check the socket and the power supply fuse.

Remedy:

• Check the mains cable and the mains plug of the device.

Remedy:

• Check all parts for clogging.

Remedy:

• Check the fit of all electrical connections.

Cause:

Suction turbine rotating in the wrong direction

Remedy:

• Swap the pins on the plug.

  ---



Cause:

Filter, nozzle, suction hose or suction pipe clogged.

Remedy:

• Check the accessory for clogging.

Remedy:

• Clean the accessory if necessary.

Remedy:

• Clean the filter.

Remedy:

• Replace the filter if necessary.

Cause:

Filter not correctly fastened or faulty.

Remedy:

• Clean the filter and insert it correctly.

Remedy:

• Check the filter for faults and replace if necessary.

We hereby declare that the machine described below complies with the relevant basic safety and health requirements in the EU Directives, both in its basic design and construction as well as in the version placed in circulation by us. This declaration is invalidated by any changes made to the machine that are not approved by us.

Product: Wet/dry vacuum cleaner

Type: 9.988-xxx

2006/42/EC (+2009/127/EC)

2014/30/EU

2011/65/EU

EN 55014-1: 2017 + A11: 2020

EN 55014-2: 2015

EN 60335-1

EN 60335-2-69

EN IEC 61000-3-2: 2019

EN 61000-3-3: 2013 + A1: 2019

EN 61000-3-11: 2000

EN 62233: 2008

EN IEC 63000: 2018

-

The signatories act on behalf of and with the authority of the Executive Board.

---

Documentation supervisor:

A. Haag

Kärcher Industrial Vacuuming GmbH

Robert-Bosch-Straße 4-8

73550 Waldstetten (Germany)

Ph.: +49 7171 94888-0

Fax: +49 7171 94888-528

Waldstetten, 2024/04/01

We hereby declare that the product described below complies with the relevant provisions of the following UK Regulations, both in its basic design and construction as well as in the version put into circulation by us. This declaration shall cease to be valid if the product is modified without our prior approval.

Product: Wet/dry vacuum cleaner

Type: 9.988-xxx

S.I. 2008/1597 (as amended)

S.I. 2016/1091 (as amended)

S.I. 2012/3032 (as amended)

EN 55014-1: 2017 + A11: 2020

EN 55014-2: 2015

EN 60335-1

EN 60335-2-69

EN IEC 61000-3-2: 2019

EN 61000-3-3: 2013 + A1: 2019

EN 61000-3-11: 2000

EN 62233: 2008

EN IEC 63000: 2018

-

The signatories act on behalf of and with the authority of the Executive Board.

---

Documentation supervisor:

A. Haag

Kärcher Industrial Vacuuming GmbH

Robert-Bosch-Straße 4-8

73550 Waldstetten (Germany)

Ph.: +49 7171 94888-0

Fax: +49 7171 94888-528

Waldstetten, 2024/04/01

• IVS 100/40

• IVS 100/55

• IVS 100/75
